4' x 8' Ground Protection Mats for Heavy Equipment

Ground Protection Mat is a high load capacity mat boasting an aggressive diamond plate tread design on both sides of the mat and a high load capacity ideal for use over soft or sensitive ground conditions in the construction, civil engineering, groundwork, and events industries. These rugged mats are made of 0.5in. (12.7 mm) thick polyethylene making them virtually indestructible. We can withstand loads of up to 120 tons*, and its flexible construction means that these mats will follow the contours of the ground to deliver a highly effective access solution over undulating or sloping ground conditions. we can be easily deployed and maneuvered without any special equipment with the added optional convenience of strategically positioned hand holes.

*Load bearing capacity is subject to ground conditions.  Sizing is subject to a manufacturing variance of +/- 5%.

Loading Weight of Polymer Composite Plastic Construction Road Plate Ground Protection Mat

Size	Thickness	Weight	Loading Weight
915x2440mm	12.7mm	31.25KGS	50 Tonnes
1220x1830mm	15mm	36.39KGS	60 Tonnes
1220x2440mm	20mm	63.40KGS	80 tonnes
1000x3000mm	25mm	78.90KGS	100 tonnes
2000x5900mm	30mm	369.34KGS	120 tonnes
